XBLink - BVLOS 4G Connectivity for Drones
As low as $685.00
Short Descriptions
Discontinue - 4G LTE connectivity for UAVs
XBLink is a Plug and Play hardware for BVLOS Flight based on Real time 4G LTE connective.
Update to XBLink Plus
Included 1 year XBStation accounts ($99)
Usually ship within 2-4 days (business day) after payment.
Introduction
https://xbstation.com/store/xblink
Documment
Package Includes
| Quantity | Name |
| 1 | XBLink |
| 1 | XBCam |
| 1 | Telemetry Cables |
| 1 | Power Cables |
| 1 | Micro HDMI Cables |
| 2 | 4G LTE Antenna |
| 2 | 4G LTE Antenna Cable |
Spectifications
| Product Performance | Detail |
|---|---|
| Autopilot | Pixhawk Cube, Pixhawk 4,Pixhawk etc... |
| Data protocol | Mavlink1, Mavlink2 |
| Camera | XBCam 8 MP |
| Video output | 1080P、720P、480P、320P - Custom |
| Video codec | H264 |
| Video input | CSI (XBCam 8 MP) , HDMI (option - need extension board) |
| Voltage input | 7 - 30V |
| Temperature | -10 - +60°C |
| Size | 73.4mmX43.4mmX18.5mm |
| Weight | 74 grams |
| Support | Windows, MacOS, Android |
| Software | XBStation PilotApp |
| Compatible | Mission Planner, Qgroundcontrol |
| Region | Global (All countries) |
| Antenna interface | MMCX |
XBCam
XBLink is coming with XBCam (720p 170FOV Wide Angle Camera - Aluminum cover)
By using high speed HDMI cable, It will make the camera connection stronger, solid, easy to mount and integrate in even the space-constricting UAV designs.
XBCam is CSI camera with native HDMI interface. Therefore, it allows to achieve the lowest latency physically possible when compare with USB or HDMI ouput camera.
| Product Performance | Detail |
|---|---|
| Size | 26mmX26mmX23mm |
| Weight | 14.5 grams |
| Megapixels | 8 Megapixels |
| Field of view (FOV) | 160 degree |
Note:
- XBLink works normally without cooling fan. If you use XBLink in hot weather or closed box environment, adding Cooling Fan will help XBLink not overheat and ensure performance.
- Cable option
+ JST-GH to JST-GH: Pixhawk 2 Cube, Pixhawk 4, ...
+ JST-GH to DF-13: Pixhawk 2.4.8 (old Pixhawk)
| Serial Cable | |
| Cooling Fan | |
| RAM | 2G |
